Praher Plastics

1 1/2" Single Union Blocked Ball Valve MIP x MIP

Product #:PRA-56-4128

Mfg. Part #:150-0155


Praher Plastics 150-0155 1 1/2" Single Union Blocked Ball Valve MIP x MIP

Praher Plastics

1 1/2" Single Union Blocked Ball Valve MIP x MIP

Product #:PRA-56-4128

Mfg. Part #:150-0155

Description

Praher's unique pinned true single union ball valve design provides for: user friendly handle operation - union nut load does not transfer onto ball seat, thereby providing user with easy handle operation even if valve not operated for a long period of time. "below grade - blocked seat flooded suction design" - valve seat will not blow out from static pressure if union nit is removed.

Documents

No documents available

Feature Bullets

  • Praher's unique pinned true single union ball valve design provides for:
  • User friendly handle operation - union nut load does not transfer onto ball seat, thereby providing user with easy handle operation even if valve not operated for a long period of time
  • Below grade - blocked seat flooded suction design - valve seat will not blow out from the static pressure if union nut removed.
  • Branch Availability

    content loaded

    Specifications

    • BrandPraher Plastics
    • ApplicationPool, Spa, Irrigation
    • Shipping Dimensions7 x 5 x 4 inch
    • ColorWhite
    • Commercial, Residential, or ProfessionalResidential
    • Each Product Weight1.1 pound
    • Master Carton Quantity100
    • MaterialPVC or Polyvinyl Chloride
    • Minimum Sell Quantity1
    • Orifice1.5 inch
    • Pressure Rating150 pounds per square inch
    • Valve ColorWhite
    • Valve Connection ConfigurationMIP
    • UPC Code885531000381
