AquaStar Pool Products

12" Square Retrofit Moflow™ Suction Outlet Cover Black

Product #:API-25-2169

Mfg. Part #:R12MF102


AquaStar Pool Products R12MF102 12" Square Retrofit Moflow™ Suction Outlet Cover

AquaStar Pool Products

12" Square Retrofit Moflow™ Suction Outlet Cover Black

Product #:API-25-2169

Mfg. Part #:R12MF102

Description

AquaStar Pool Products R12MF102 12" Square Retrofit Moflow™ Suction Outlet Cover for retrofit only, does not include mud frame. Easily and safely retrofits to most brands' 1" deep 12" square existing frames, does not include mud frame. Manufactured from superior UV-resistant engineered polymers. Online product support including downloadable General Certificate of Conformity, third-party certificate, installation instructions and more. Replace cover every five years from the date of installation.

Documents

Feature Bullets

  • For retrofit only, does not include mud frame
  • Easily and safely retrofits to most brainds' 1" deep 12" square existing frame
  • All components meet or exceed ANSI/APSP 16-2011 and NSF/ANSI 50-2009a national standards and ASTM G154 UV testing exposure

    • Branch Availability

    content loaded

    Specifications

    • BrandAquaStar Pool Products
    • Commercial, Residential, or ProfessionalCommercial
    • Shipping Dimensions11.25 x 11.25 x 2.5 inch
    • Cover Open Area69.1 square inch
    • Each Product Weight2.22 pound
    • Floor Flow Rate Measure A274 gal/min
    • For Use WithAquaStar "R" 12 Inch Models, Hayward, Waterway, American (Pentair #2 selling), PacFab with 1 Inch Deep Existing Frames and Four Screw Hole Pattern
    • Includes12 Inch Square Retrofit Moflow Suction Outlet Cover, (4) 10 x 1-1/2 Inch Lg Flat Head PhillipsType A 316 Stainless Steel Screw, (4) 10-24 x 1-1/4 Inch Lg Flat Head Phillips Machine 316 Stainless Steel Screw, (4) #10 x 1 Inch Lg Flat Head Phillips Type A 3
    • Master Carton Quantity10
    • MaterialPolymer
    • Minimum Sell Quantity1
    • Pallet Quantity1
    • Standards ApprovalsNSF Certified, ANSI Certified, APSP Certified, ASTM Certified
    • Wall Flow Rate Measure A278 gal/min
    • Floor Flow Rate Measure A at1.3 ft/s
    • For Use WithAquaStar "R" 12 Inch Models, Hayward, Waterway, American (Pentair #2 selling), PacFab with 1 Inch Deep Existing Frames and Four Screw Hole Pattern
    • Wall Flow Rate Measure A at1.3 ft/s
    • UPC Code0883612080536

    Parts & Schematics

    There are no parts or schematics available.

    Wholegoods

    There are no wholegoods available.
