Corona Lighting

2-1/2" Black Aluminum LED Mini Bullet Directional Light 5W 2700K

Product #:CNA-96-1177

Mfg. Part #:CL-505-BK-L-ED16-5W-FL


Corona Lighting CL-505-BK-L-ED16-5W-FL 2-1/2" Black Aluminum LED Mini Bullet Directional Light 5W 2700K

Corona Lighting

2-1/2" Black Aluminum LED Mini Bullet Directional Light 5W 2700K

Product #:CNA-96-1177

Mfg. Part #:CL-505-BK-L-ED16-5W-FL

EA

Description

Corona Lighting CL-505-BK-L-ED16-5W-FL 2-1/2" Black Aluminum LED Mini Bullet Directional Light 5W 2700K is encased in a diecast aluminum housing and has a 360 degree rotatable shroud. The fixture is equipped with a lens that is a clear, tempered, and heat resistant glass. The socket is a top-grade, ceramic bi-pin socket, with retention clip to securely hold lamp in place.

Documents

Feature Bullets

  • Housing: Die-cast aluminum. 350 degree rotatable shroud.
  • Finish: Polyester UV powder coated, Black.
  • Lens: Clear, tempered, and heat resistant glass
  • Socket: Top grade fixed ceramic bi-pin socket, with lamp retension clip to securely hold lamp in place
  • Lamp: LED 5W
  • Wiring: Fixture is prewired with a 3ft 18-2 SPT1-W direct burial cord.
  • Gasket: Silicone gasket for weather-tight sealing
  • Knuckle: Adjustable die-cast aluminum knuckle with philips screw and 1/2" NPT threaded male hub on bottom
  • Mounting spike: 8 1/2" Black ABS spike with 1/2" NPT threaded male hub
  • Electrical notes: Voltage range for LED lamps are 9v-17V

    • Branch Availability

    content loaded

    Specifications

    • BrandCorona Lighting
    • ApplicationUniversal
    • Shipping Dimensions10 x 6 x 6 inch
    • ColorBlack
    • Each Product Weight1 pound
    • FinishPowder Coated
    • MaterialAluminum
    • Minimum Sell Quantity1
    • Warranty - AdditionalParts - 1 year
    • Wattage5 watt
    • Average Life50000 hours
    • Beam AngleFlood
    • Beam Spread (deg)45
    • ChannelConstruction Channel
    • Commercial, Residential, or ProfessionalCommercial, Professional, Residential
    • DimmableFalse
    • Fastener MaterialABS or acrylonitrile butadiene styrene
    • Lead Wire Length3 foot
    • Lens TypeClear, tempered, and heat resistant glass.
    • Light Bulb Base TypeBI Pin
    • Lighting Product TypeAccent Lights
    • Lighting StyleModern
    • MountingSingle Post to Floor
    • Overall Height15.75 inch
    • Product Height15.75 inch
    • Product Width2.5 inch
    • Warranty - General5 years
    • UPC Code683374825051
