Century

2-Speed Two-Compartment Pool Filter Motor 1/0.13HP 230V

Product #:AOS-60-5251

Mfg. Part #:STS1102RV1


Century® STS1102RV1 2-Speed Two-Compartment Pool Filter Motor; 1/0.13 HP, 3450/1725 RPM, 230 V, 56J, Threaded Shaft

Century

2-Speed Two-Compartment Pool Filter Motor 1/0.13HP 230V

Product #:AOS-60-5251

Mfg. Part #:STS1102RV1

Description

Century® STS1102RV1 2-Speed Two-Compartment Pool Filter Motor; 1/0.13 HP, 3450/1725 RPM, 230 V, 56J, Threaded Shaft. Century® NEMA C-Flange swimming pool filter pump motors are carefully engineered to meet the rugged demands of pool duty. Two sealed ball bearings (with large 304 bearing on shaft end) offer ample capacity for extended life. Bearings are selected for quietness and are lubricated for life with greases specifically chosen for moisture and heat resistant qualities. Aluminum end frames are accurately machined for maximum concentricity and minimum runout.

Branch Availability

content loaded

Specifications

  • BrandCentury
  • Ambient Temperature50 degrees Celsius
  • Shipping Dimensions21.06 x 9.5 x 9.5 inch
  • Amps High Speed7
  • Amps Low Speed2.3
  • ApplicationPool
  • Bearing TypeSealed Ball
  • ColorBlack
  • Duty CycleContinuous
  • Each Product Weight30 pound
  • Efficiency GroupHigh
  • Frequency Rating (Hz)60
  • Horsepower1 horse power
  • Insulation ClassB
  • Master Carton Quantity1
  • Minimum Sell Quantity1
  • Motor Enclosure TypeOpen Drip Proof
  • Motor Frame Size56J
  • Motor Shaft RotationCounterclockwise Pulley End
  • Motor Speed2-Speed
  • Motor Thermal ProtectionAutomatic Reset
  • Pallet Quantity30
  • PhaseSingle
  • RPMs Max3450
  • RPMs Min1725
  • Service Factor1.5
  • Shaft DesignThreaded
  • Shaft Diameter0.625 inch
  • Shaft Length2.5625 inch
  • Shaft Material303 Stainless Steel
  • Standards ApprovalsCSA Certified
  • Voltage230V
  • Diameter6.5 inch
  • Flange MaterialAluminum
  • Frame MaterialRolled Steel
  • Green or Energy Efficient ProductTrue
  • Motor Capacitor TypeStart
  • Motor RatingFull-Rated
  • Thrust HP1.5
  • UPC Code786674031860
