Century

2-Speed Two-Compartment Pool Filter Motor 1.5/0.25HP 230V

Product #:AOS-60-5227

Mfg. Part #:STS1152R


Century® STS1152R 2-Speed Two-Compartment Pool Filter Motor; 1.5/0.25HP, 1 Ph, 60 Hz, 230 V, 3600 RPM, 56J Frame, ODP

Century

2-Speed Two-Compartment Pool Filter Motor 1.5/0.25HP 230V

Product #:AOS-60-5227

Mfg. Part #:STS1152R

Description

Century® NEMA C-flange swimming pool filter pump motors are carefully engineered to meet the rugged demands of pool duty. Two sealed ball bearings (with large 304 bearing on shaft end) offer ample capacity for extended life. Bearings are selected for quietness and are lubricated for life with greases specifically chosen for moisture and heat resistant qualities. Aluminum end frames are accurately machined for maximum concentricity and minimum runout.

Branch Availability

content loaded

Specifications

  • BrandCentury
  • Ambient Temperature40 degrees Celsius
  • Shipping Dimensions20.5 x 9.5 x 11.25 inch
  • Amps High Speed9
  • Amps Low Speed3.3
  • ApplicationPool
  • Bearing TypeSealed Ball
  • ColorBlack
  • Duty CycleContinuous
  • Each Product Weight31.5 pound
  • Efficiency GroupHigh
  • Frequency Rating (Hz)60
  • Horsepower1.5 horse power
  • Insulation ClassB
  • Material303 Stainless Steel
  • Minimum Sell Quantity1
  • Motor Enclosure TypeOpen Drip Proof
  • Motor Frame Size56J
  • Motor Shaft RotationCounterclockwise Pulley End
  • Motor Speed2-Speed
  • Motor Thermal ProtectionAutomatic Reset
  • Pallet Quantity30
  • PhaseSingle
  • RPMs Max3450
  • RPMs Min1725
  • Service Factor1.3
  • Shaft Design7/16 Threaded
  • Shaft Diameter0.625 inch
  • Shaft Length2.5625 inch
  • Shaft Material303 Stainless Steel
  • Standards ApprovalsCSA Certified
  • Voltage230V
  • Diameter6.5 inch
  • Flange MaterialAluminum
  • Frame MaterialRolled Steel
  • Green or Energy Efficient ProductTrue
  • Motor Capacitor TypeStart, Run
  • Motor RatingFull-Rated
  • Thrust HP1.95
  • UPC Code786674031877
