FEBCO

2" Y Pattern Reduced Pressure Zone Backflow Preventer Assembly with Shut-Off Vlv

Product #:FEB-58-1020

Mfg. Part #:825HBV

  • This product is obsolete.
  • The superseded product was not found.

FEBCO 825HBV 2" Bronze Y Pattern Reduced Pressure Zone Backflow Preventer Assembly with Quarter Turn Ball Shut-Off Valve

FEBCO

2" Y Pattern Reduced Pressure Zone Backflow Preventer Assembly with Shut-Off Vlv

Product #:FEB-58-1020

Mfg. Part #:825HBV

EA

Description

FEBCO 825HBV 2" Bronze Y Pattern Reduced Pressure Zone Backflow Preventer Assembly with Quarter Turn Ball Shut-Off Valve. This 2 inch Y pattern reduced pressure zone backflow preventer assembly is designed to prevent the reverse flow of high hazard (toxic) fluids found in the water from entering into the potable water supply due to back siphonage and or backpressure in accordance with national plumbing codes and water authority requirements. It is used in water services to industrial plants, hospitals, morgues, mortuaries, and chemical plants and is also used in irrigation systems, boiler feed, water lines and other installations requiring maximum protection. This assembly consists of a bronze body, threaded quarter turn ball valves, test cocks, spring loaded Y pattern check valves, and one hydraulically dependent differential relief valve.

Documents

No documents available

Feature Bullets

  • Bronze body
  • Modular relief valve for easy maintenance
  • Replaceable seat rings for longer valve life
  • NPT end connection
  • Meets all specifications of AWWA, ASSE
  • Low head loss for optimum performance
  • Quarter turn ball valves
  • Stainless steel springs
  • Nitrile elastomers
  • Branch Availability

    content loaded

    Specifications

    • BrandFEBCO
    • ChannelConstruction Channel
    • Shipping Dimensions19.75 x 11.75 x 10.25 inch
    • Each Product Weight34.65 pound
    • Minimum Sell Quantity1
    • UPC Code643925002133

    WARNING: The following product(s) can expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov

    Parts & Schematics

    There are no parts or schematics available.
