Century® H705V1 3-Phase Pool and Spa Pump Motor; 2HP, 3450/2850 RPM, 208-230/460V, 56J, Threaded Shaft
Description
Century® is an established and respected motor brand with reliable and dependable products for HVAC, pool & spa, and commercial and industrial applications. For nearly 80 years, the Century brand has delivered cutting-edge, high-quality, and energy-efficient solutions to customers all over the world. Century brings cutting edge, high quality and energy efficient solutions to customers all over the world. For your most relaxing applications, Century® pool pump motors have you covered to ensure your summer and leisure activities stay up and running.
Branch Availability
content loaded
Specifications
- BrandCentury
- Ambient Temperature40 degrees Celsius
- Shipping Dimensions18.63 x 9.5 x 9.5 inch
- Amps High Speed5.8
- Amps Low Speed2.75
- ApplicationPool
- Bearing TypeBall
- ColorBlack
- Duty CycleContinuous
- Each Product Weight35 pound
- Frequency Rating (Hz)50/60
- Horsepower2 horse power
- Insulation ClassA
- Master Carton Quantity1
- Minimum Sell Quantity1
- Motor Enclosure TypeOpen Drip Proof
- Motor Frame Size56J
- Motor Shaft RotationClockwise, Counterclockwise
- Motor Thermal ProtectionNone
- Pallet Quantity1
- PhaseThree
- RPMs Max3450
- RPMs Min2850
- Service Factor1.2
- Shaft DesignThreaded
- Shaft Diameter0.625 inch
- Standards ApprovalsCSA Certified
- Voltage208V, 230V
- ChannelNone
- Commercial, Residential, or ProfessionalCommercial
- Diameter6.5 inch
- Flange TypeRound
- Frame MaterialRolled Steel
- Motor RatingFull-Rated
- UPC Code786674024121
