Rain Bird
TSJ100PRS 1" x 12" Swing Joint with 70 psi Pressure Regulator
Product #:RBD-58-3017
Mfg. Part #:A66755

Rain Bird A66755 TSJ100PRS 1" x 12" Swing Joint with 70 psi Pressure Regulator
Rain Bird
TSJ100PRS 1" x 12" Swing Joint with 70 psi Pressure Regulator
Product #:RBD-58-3017
Mfg. Part #:A66755
Description
The Rain Bird Turf Swing Joint with Pressure Regulating System (TSJ-PRS) controls and maintains a preset inlet pressure for rotors with 1" inlets. Pressure regulation right at the rotor gives designers more control over the irrigation system performance than other means of regulation. In very high pressure or fluctuating pressure situations, the TSJ-PRS ensures optimal droplet size and eliminates misting, resulting in improved uniformity and reduced water consumption. The TSJ-PRS can also be used to provide the same pressure to each rotor on a zone in applications where high flow rates result in significant friction losses or where there are elevation changes.
Documents
Branch Availability
content loaded
Specifications
- BrandRain Bird
- Each Product Weight1.6 pound
- Shipping Dimensions1.34 x 0.82 x 0.71 inch
- Master Carton Quantity15
- Minimum Sell Quantity1
- Pallet Quantity225
- Pressure Rating Max70 pounds per square inch
- UPC Code753810017330
