Century® Guardian® USQG1152A Two-Compartment Pool Pump Motor; 1.5HP, 1 Ph, 60 Hz, 230/115 V, 3600 RPM, 48Y Frame, ODP
Description
Powerful and reliable this Guardian Square Flange Pool Pump Motor 1.5 HP 230/115V is able to perform in tough environmental conditons. This motor is designed for long-term performance, and made with high-quality parts and materials.
Branch Availability
content loaded
Specifications
- BrandCentury
- Ambient Temperature50 degrees Celsius
- Shipping Dimensions20.13 x 9.5 x 11 inch
- Amps High Speed19.2
- Amps Low Speed9.6
- ApplicationPool
- Bearing TypeBall
- ColorBlack
- Duty CycleContinuous
- Each Product Weight29 pound
- Frequency Rating (Hz)60
- Horsepower1.5 horse power
- Insulation ClassB
- Master Carton Quantity1
- Minimum Sell Quantity1
- Motor Enclosure TypeOpen Drip Proof
- Motor Frame Size48Y
- Motor Shaft RotationCounterclockwise Pulley End
- Motor Thermal ProtectionAutomatic Reset
- Pallet Quantity30
- PhaseSingle
- RPMs Max3450
- RPMs Min3450
- Service Factor1.1
- Shaft DesignThreaded
- Shaft Diameter0.625 inch
- Shaft Length0.5 inch
- Shaft MaterialStainless Steel
- Standards ApprovalsCSA Certified
- Voltage115V, 230V
- Commercial, Residential, or ProfessionalResidential
- Diameter5.625 inch
- Flange TypeSquare
- Frame MaterialSteel
- Motor Capacitor TypeStart
- Shaft Height3.25 inch
- UPC Code786674033307
